Relief valves 1/4" BSPT

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

A high lift safety relief valve with atmospheric discharge suitable for air and inert gas applications. The valve automatically vents at the selected pressure and resets when the pressure returns to "normal". Atmospheric discharge with pull ring easing gear. Applications include compressed air cylinders and pressure vessels.

Safety valves are PED approved and CE Marked.

Capacity shown is for air at 15 deg C in std litres/sec at 10% overpressure for the nearest size in the data sheet and is a guide only.

These valves are supplied with test certificate - see datasheets for example. The test certificate includes the batch number which is also stamped on the base of the valve.

On request:other set pressures and special version with a silicone rubber seat for small dental and hospital sterilizers.

Technical Details

Materials:

Brass body with stainless steel springs

Connection:

1/4" BSP Male

Temperature:

-15 to +140 deg C

Manufacturers ref:

DF60 (or 6000 Series)

Datasheets

Relief valves 1/4 BSPT datasheet
Click Below

1) Dereve_DF60

2) Dereve_DF60_Sample_Cert

Prices (Click quantity for more availability info)

Pressure	Capacity	Order Code	Available	1+	5+
3.5 bar	24 l/s	106501	2	£47.30	£42.04
5.0 bar	36 l/s	106502	2	£47.30	£42.04
5.5 bar	-	106746	3	£47.30	£42.04
7.9 bar	57 l/s	106503	2	£47.30	£42.04
8.6 bar	64 l/s	106504	2	£47.30	£42.04
9.0 bar	-	106519	6	£47.30	£42.04
9.7 bar	73 l/s	106505	3	£47.30	£42.04
11.0 bar	-	106518	3	£47.30	£42.04
11.2 bar	86 l/s	106506	4	£47.30	£42.04
13.1 bar	72 l/s	106507	2	£47.30	£42.04
16.0 bar	110 l/s	122661	2	£47.30	£42.04

(All Prices Exclude VAT)
